Rh-CPR300s
| Quantity: | |
|---|---|
RH-CPR300S Comprehensive emergency skills training
Product Description
Executive standard: American heart association (AHA) 2015 international guidelines for cardiopulmonary resuscitation (CPR) &
cardiovascular first aid (ECC).
CPR Manikin Function:
★The pupil adopts the LCD screen to simulate the state of pupil narrowing, normal and dilation. Under the state of rescue, the
pupil dilated and the pupil narrowed and restored to light emission after rescue.
★The joints of the simulated human upper limbs can move freely. (Before and after spin, stretch, stretch, spin in, spin out) The
wrist and elbow joints can be flexion and extension. Can practice patient handling
★Equipment fault self-test function: after starting the machine, the equipment will automatically enter the self-test program to
check whether the equipment has faults
★The key operation adopts fault-tolerant technology
★The chest cage is newly added to detect insufficient rebound
Manikin vital signs:
1) Initial state: No pulsating carotid artery, simulating dilated pupil
2) In the process of pressing; Manikin carotid artery passive pulsation, pulse frequency and compression frequency consistent
3) After successful rescue; Carotid artery beating autonomously, simulating pupil constriction and recovery of light reflex
I I Standard airway can be opened and the airway indicator light is on
I Artificial hand chest compressions and artificial respiration can be performed
I I Manual chest compressions:
1. Dynamic barcode indicator shows the depth of compression: the correct depth of compression (5-6cm area) is displayed by the
green bar code, the depth of compression is not enough (less than 5cm) is shown by the yellow bar code, and the depth of
compression is too deep (more than 6cm) is shown by the dynamic feedback of the movement of the red bar code indicator
2. LCD count and frequency display; Keep detailed records of the specific reasons for wrong pressing (too much pressing force,
too ittet pressing force, wrong pressing position, too fast pressing frequency, too slow pressing frequency, etc.)
I I I Artificial mouth-to-mouth breathing (blowing):
1. The dynamic bar code indicator displays the tidal volume: the tidal volume blown in is correct (500ml-600ml- 1000ml), and the
tidal volume blown in is too small or too large, and the tidal volume moved by the bar code yellow or red indicator respectively
2. Liquid crystal counting display: the specific causes of air blowing errors are recorded in detail (according to excessive air
blowing volume, air blowing into the stomach, air blowing force is too small, and the number of correct air blowing)
I I Ratio of compressions to breaths: 30:2 (single or double)
Operating cycle: 30 effective compressions and 2 manual blows, 30:2 5- cycle CPR
Three operation methods: CPR training, simulation test and practical test
CPR display function:
Electronic monitoring: electronic monitoring of airway opening and compression site, showing correct and incorrect number of
artificial respiration and cardiac compressions.
The operating time can be set in seconds.
Operating frequency: 100-1 20 times/min.
Operation time: in seconds.
Check pupils: narrow and contrast.
Power status: 220V power supply is adopted, and 12V power supply is output after the voltage is stabilized by the stailizer
Printer functions:
You can select the printing process after the end of the operation.
Two types of short and long printing, short printing records the results of pressing and blowing in the whole operation process,
comprehensive judgment and score; Long print overlay short print on the basis of showing pressure and blow waveforms.
The controller is equipped with lithium battery and need no be connected to 220V power supply.
New electronic remote control function: teachers can remote control CPR start, stop, reset, mode selection, pupil change,
carotid pulse, printer and other functions by remote control.
Nursing functions:
1. The simulated person can lie on the back and bend the knee, support the legs independently after abduction, and rotate the
upper arms and legs flexibly.
2, holistic care: bath on the bed, wear change clothes, cold, heat therapy.
3. Arm intravenous injection and blood transfusion training
Subcutaneous deltoid injection
5. Intramuscular injection of buttocks and thighs
6. Male and female catheterization
7. Nursing of fistula and drainage
Parameter
| Model Type | Function | Function Features | Configuration Content |
| RH-CPR300S | CPR | Manikin,Cotroller |
FAQ
Q:What are the main products?
A:Power Flower's main products are hospital beds,surgical equipment, medical trolleys& stretchers and stainless steel trolleys and so on.
Q: Why to trust us?
A: All products have ISO and CE with high Quality and Constantly updating.
Q:When do you start?
A: We are absorbed in producing hospital equipment in 2018.
Q:Is OEM available by your company?
A:OEM service is always available.
Quotation offered in 3 days based on customer's requirements.
Q:What is the delivery time of the products?
A: Normally 10-15days.
Q:Free sample available or not?
A: Sample cost will be refund after first bulk order.
Q:How long is the warranty period for you products?
A:Quality assurance 2(two) years.
Q:What are the brands of the important parts that make up the operating bed?
A:Motor parts:JIECHANG.LINAK.LINKAN.Dewert;
B:Electro-hydraulic system:Made In Germany,Superchumbo Made Mix,Made in US;
Q:Does your factory accept customization of products?
A:Of Course.Welcome to Customization.
COMPANY SLOGAN
We believe that"customer first, quality foremost" and will leadour clients to create a more splendid future with our constantlyhard working,best service and the reasonable price.
COMPANY INTRODUCTION
Suzhou Power Flower Biotech Co.,Ltd. is a company specializing in the production and sale of medical devices.It is located in Zhangjiagang City,a national civilized city.The location is excellent and the transportation is convenitent.The main products are:operating room equipment,ward nursing equipment,rehabilitation and pension series,medical first aid series,medical equipment of various departments;Operating import and export business of Class I,Class II and Class III Medcial products and medical products;The strength of selling medical products has won the support and trust of customers and partners with good reputation,honest operation,high-quality product sales and first-call service standards.The company's service aim is:customer first,quality as surance,integrity-based!
